JZG60 Thermal Insulation Casement Window Anodized Custom Casement Windows

JZG60 Thermal Insulation Casement Window Anodized Custom Casement Windows

Brand Name: FOCHEW
Model Number: JZG60
MOQ: 20 m²
Price: $68-100
Payment Terms: ,T/T
Supply Ability: 200000m²
Detail Information
Place of Origin:
CHINA
Certification:
ISO.SIRIM
Window Type::
Casement Window
Frame Material::
Aluminum Alloy
Profile Thickness:
1.2-1.6 Mm (Aluminum)
Glass Options:
Single Glass / Double Glazing (5mm + 12A + 5mm) / Low-E Glass
Hardware:
Stainless Steel Hinges, Multi-point Locking System
Sealing System:
EPDM Sealing Strip
Surface Finish:
Powder Coating / Anodized / Wood Grain
Standard Colors::
White, Black, Grey, Customized
Wind Load Resistance:
≥ 2500 Pa
Thermal Insulation:
Uw ~1.7-2.2 W/m²*K (depending On Glass Configuration)
Sound Insulation::
~27-30 DB
Opening Angle::
0–90°
Highlight:

JZG60 Thermal Insulation Casement Window

,

Thermal Insulation Casement Window Anodized

,

Anodized Custom Casement Windows

Product Description
JZG60 Thermal Insulation Casement Window

High-performance casement window system designed for superior thermal and acoustic insulation in demanding architectural applications.

Key Features
  • Excellent sound and thermal insulation properties
  • Outstanding airtightness and watertightness
  • High wind pressure resistance
Recommended Applications
Application Type Description
High-end Villas Premium residential properties requiring superior insulation
Luxury Clubs Exclusive venues with high acoustic and thermal performance demands
Specialty Buildings Structures with exceptional sound/thermal insulation requirements
